| Place of Origin: | China |
|---|---|
| Brand Name: | TOBO |
| Certification: | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Model Number: | ASTM A234 WP12 |
| Minimum Order Quantity: | 1PC |
| Price: | negotiation |
| Packaging Details: | PLY-WOODEN CASE OR PALLET |
| Delivery Time: | 15 work days |
| Payment Terms: | T/T, D/P, D/A, Western Union |
| Supply Ability: | 9800000PCS Per month |
| Product Name: | Carbon Steel Fittings | Standard: | ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 |
|---|---|---|---|
| Type: | Pipe Fitting | Application: | Petroleum, Chemical, Machinery, Electric Power, Shipbuilding, Papermaking, Construction, Etc |
| Technology: | Hot Formed /cold Formed /forged Elbow | Pressure: | SCH5-SCH160,XXS |
| Connection: | Seam &Seamless Or Welded,butt Weld | Diameter: | 22MM-820MM |
| Highlight: | butt weld tube fittings,industrial pipe fittings |
||
Carbon Steel Pipe Fittings ASTM A234 WP12 Large Size Caps DN15 to DN1400
| Material: | Carbon Steel | Technics: | Butt-welding | Type: | Pipe fitting |
| Place of Origin: | Shanghai, China (Mainland) | Brand Name: | TOBO | Connection: | Welding |
| Shape: | Equal | Head Code: | Round |
| Packaging Details: | wooden case,pallets or as per customers' requirements |
| Delivery Detail: | 7---45 days according the quantity |
TOBO Steel are Manufacturer, Exporter and Supplier of Large size caps. These Large size caps are widely well-known for the utmost output and outstanding results that it gives. Large size caps manufactured using superior grade raw materials. Large size caps are used for connecting pipes of different diameters and find wide applications in various chemicals, construction industries, paper, cement & ship builders.
Nominal Pipe Size (NPS) | Outside Diameter | End to End | |||
Cap | |||||
A | B | D | E | E1 | Limit Wall Thick |
15 20 25 32 40 | ½ ¾ 1 1¼ 1½ | 21.7 27.2 34.0 42.7 48.6 | 25.4 25.4 38.1 38.1 38.1 | - - - - - | - - - - - |
50 65 80 90 100 | 2 2½ 3 3½ 4 | 60.5 76.3 89.1 101.6 114.3 | 38.1 38.1 50.8 63.5 63.5 | 44.5 50.8 63.5 76.2 76.2 | 5.5 7.0 7.6 8.1 8.6 |
125 150 200 250 300 | 5 6 8 10 12 | 139.8 165.2 216.3 267.4 318.5 | 76.2 88.9 101.6 127.0 152.4 | 88.9 101.6 127.0 152.4 177.8 | 9.5 11.0 12.7 12.7 12.7 |
350 400 450 500 550 600 | 14 16 18 20 22 24 | 355.6 406.4 457.2 508.0 558.8 609.6 | 165.1 177.8 203.2 228.6 - - | 190.5 203.2 228.6 254.0 - - | 12.7 12.7 12.7 12.7 - - |
650 700 750 800 850 900 950 | 26 28 30 32 34 36 38 | 660.4 711.2 762.0 812.8 863.6 914.4 965.2 | - - - - - - - | - - - - - - - | - - - - - - - |
1000 1050 1100 1150 1200 | 40 42 44 46 48 | 1016.0 1066.8 1117.6 1168.4 1219.2 | - - - - - | - - - - - | - - - - - |
Nominal Pipe Size (NPS) | Outside Diameter at Bevel D | End-to-End | ||
CAP | ||||
Length(1) | Limiting Wall thickness for length "E" | Length(2) | ||
E | E1 | |||
½ ¾ 1 1¼ 1½ | 0.84 1.05 1.32 1.66 1.90 | 1.00 1.00 1.50 1.50 1.50 | 0.18 0.15 0.18 0.19 0.20 | 1.00 1.00 1.50 1.50 1.50 |
2 2½ 3 3½ 4 | 2.38 2.88 3.50 4.00 4.50 | 1.50 1.50 2.00 2.50 2.50 | 0.22 0.28 0.30 0.32 0.34 | 1.75 2.00 2.50 3.00 3.00 |
5 6 8 10 12 | 5.56 6.62 8.62 10.75 12.75 | 3.00 3.50 4.00 5.00 6.00 | 0.38 0.43 0.50 0.50 0.50 | 3.50 4.00 5.00 6.00 7.00 |
14 16 18 20 22 | 14.00 16.00 18.00 20.00 22.00 | 6.50 7.00 8.00 9.00 10.00 | 0.50 0.50 0.50 0.50 0.50 | 7.50 8.00 9.00 10.00 10.00 |
24 26 28 30 32 | 24.00 26.00 28.00 30.00 32.00 | 10.50 10.50 10.50 10.50 10.50 | 0.50 - - - - | 12.00 - - - - |
34 36 38 40 42 | 34.00 36.00 38.00 40.00 42.00 | 10.50 10.50 12.00 12.00 12.00 | - - - - - | - - - - - |
44 46 48 | 44.00 46.00 48.00 | 13.50 13.50 13.50 | - - - | - - - |
ASTM A234 WPB carbon steel pipe fittings A234 WPB Butt welded
1>Size -- Seamless:from 1/2" to 24" ,Welded:from 24" to 80" ( or as customer requirements)
2>Angle -- 22.5 deg, 30deg,45 deg,90 deg,180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D,4D,5D,6D,7D-40D.
3>Thickness--SCH10,SCH20,SCH30,STD SCH40, SCH60, XS, SCH80., SCH100, SCH120, SCH140, SCH160, XXS
4>Standard --ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605
5>Material
Carbon steel --ASTM A234WPB,,A234WPC,A420WPL6. ASTM A860 WPHY42/52/60/65/70
Stainless Steel --ASTM A403 WP304,304L,316,316L,321. etc
Alloy Steel --ASTM A234 WP12,WP11,WP22,WP5,WP9,WP91 etc .
6>Equipment -- Press machine ,Bending machine,Pushing Machine,electric bevelling machine Sand-blasting machine,etc
7>Test-- Direct reading light spectrum, hydrostatic test ,X-ray detector,ultrasonic flaw detection ,magnetic powder detector ,etc
8>Qualification-- API ,CE ,ISO and accept third inspection.
9>Packing-- in wooden cases or as your requirement
10>Application--Petroleum, chemical, machinery, electric power, shipbuilding, papermaking, construction, etc
