TOBO GROUP
TOBO International Trading(Shanghia)Co.,Ltd Tianda Oil Pipe Co., Ltd
TOBO Pipeline Equipment Co.,Ltd TPCO & TISCO Pipe(Tianjin)Co.,Ltd.
| Place of Origin: | China/Japan/Germany |
|---|---|
| Brand Name: | TOBO/TPCO/TISCO/VALIN/METAL |
| Certification: | ISO/PED/TUV/SGS/LR/BV |
| Model Number: | ASTM A554, A312, A249, A269 And A270,A688 |
| Minimum Order Quantity: | 100KGS |
| Price: | negotiable |
| Packaging Details: | in plastic bags then in bundles |
| Delivery Time: | 15days-> |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 1500 tons per month |
| Standard: | ASTM A554, A312, A249, A269 And A270,A688 | Color: | White, Silver |
|---|---|---|---|
| Size: | 1/2"-48" | Type: | Stainless Steel Welded Tube |
| Highlight: | Welded Stainless Steel Tubing,SS Welded Tube |
||
Detailed Product Description
| Test: | Squash Test, Extended Test, Water Pressure Test, Crystal Rot Test, Heat Treatment, NDT | Application: | Handrail,weldmesh Screen,door,window, Balcony,fence,furniture,etc |
| Material Grade: | 304,316,201,202, 316L,430 | Outer Diameter: | 6mm-101.6mm |
| Standard: | ASTM A554, A312, A249, A269 And A270,A688 | Surface: | Polished |
| Type: | Stainless Steel Welded Tube / Pipe | Wall Thickness: | 0.6mm-3mm |
304 316 201 202 Stainless Steel Welded Tube for Furniture ASTM A554 A312 A249
Quick Detail:
Welded Stainless Steel tube As per ASTM A249/A269,polished, for fluid and decorative
1 Standard: ASTM A249/269
2 Material:304,316,201,202, 316L,430
3 OD: 6mm-101.6mm
Wall: 0.6mm-3mm
4 Surface:polished
| Name | Stainless steel welded tube | |||||
| Standard | ASTM A554, A312, A249, A269 and A270,A688 | |||||
| Material Grade | 304,316,201,202, 316L,430 | |||||
| Size Range | 20x10mm--100x50mm,10x10mm-100x100mm, 9.53-101.6mm, we can also accept sizes above 101.6mm | |||||
| Thickness | 0.3mm - 3.0mm | |||||
| Length | 6m or as customers' request | |||||
Tolerance |
a) Outer Diameter: +/- 0.2mm | |||||
| b) Thickness: +/- 0.02mm | ||||||
| c) Length: +/- 5mm | ||||||
| Surface | 180G, 320G Satin / Hairline(Matt Finish, Brush, Dull Finish) 400G, 600G Mirror finish |
|||||
| Application | Handrail,weldmesh screen,door,window, balcony,fence,furniture,etc | |||||
| Test | Squash test, Extended test, Water pressure test, Crystal rot test, Heat treatment, NDT | |||||
Chemical Composition of Material |
Composition Material |
201 | 202 | 304 | 316L | 430 |
| C | ≤0.15 | ≤0.15 | ≤0.08 | ≤0.35 | ≤0.12 | |
| Si | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | |
| Mn | 5.5-7.5 | 7.5-10 | ≤2.00 | ≤2.00 | ≤1.00 | |
| P | ≤0.06 | ≤0.06 | ≤0.045 | ≤0.045 | ≤0.040 | |
| S | ≤0.03 | ≤0.03 | ≤0.030 | ≤0.030 | ≤0.030 | |
| Cr | 13-15 | 14-17 | 18-20 | 16-18 | 16-18 | |
| Ni | 0.7-1.1 | 3.5-4.5 | 8-10.5 | 10-14 | ||
| Mo | 2.0-3.0 | |||||
Mechanical Property |
Material Item | 201 | 202 | 304 | 316 | |
| Tensile Strength | ≥535 | ≥520 | ≥520 | ≥520 | ||
| Yield Strength | ≥245 | ≥205 | ≥205 | ≥205 | ||
| Extension | ≥30% | ≥30% | ≥35% | ≥35% | ||
| Hardness (HV) | <105 | <100 | <90 | <90 | ||
The welded stainless steel pipe is made from stainless steel by electric welding or sheet metal strips by means of forming and welding. Electrically welded tube is made of thermally without subsequent processing and hot-reducing.
Our Advantages:
1, Direct material sourcing from Bao Steel, ZPSS, TISCO.
2, More than 5 processing mills to produce the welded titanium tube for us. And also we own a steel tube mill.
3, Strong business cooperation with Bao Steel and Shanghai Minmetals.
4, More than usd$50,000,000 annual turnover.
