| Place of Origin: | China/Japan/Germany |
|---|---|
| Brand Name: | TOBO/TPCO/TISCO/VALIN/METAL |
| Certification: | ISO/PED/TUV/SGS/LR/BV |
| Model Number: | ASTM B862 weld Titanium pipe |
| Minimum Order Quantity: | 0.5-1 tons |
| Price: | negotiable |
| Packaging Details: | in plastic bags then in bundles |
| Delivery Time: | According to the qty |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 6000TONS/MONTH |
| Standard:: | ASTM B862 Weld Titanium Pipe | Color: | White Silver Gold |
|---|---|---|---|
| Types:: | ASTM B862 Weld Titanium Pipe | Outer Diameter: | 1/2"-48" |
| Highlight: | Thin Wall Steel Pipe,Steel Round Pipe |
||
ASTM B862 chemical 6 inch SCH 40 weld Titanium pipe Wall Thickness: SCH 5S - SCH 80
Quick Details
· Place of Origin: China
· Brand Name: TOBO
· Model Number: ASTM B862
· Material: Titanium
· Outer Diameter: 1/2"-48"
· Standard or Nonstandard: Standard
· Application: petrochemical
· Technique: Welded
· Grade: Ti Gr1, Gr2, Gr7, Gr12
· Wall Thickness: SCH 5S - SCH 80
· Inside Diameter: 70mm (min.)
| Packaging Details: | wooden cases, pallet or according to clients' requirements |
| Delivery Detail: | 7-25 days |
weld Titanium pipe
maximum length: 6000mm no circumferential welding seam
Outer diameter ranges: 76-630mm
ASTM B862 weld Titanium Pipe
| weld titanium pipe OD and WT list | |||
| DN | OD | WT | Length |
| 65-100 | 76MM-114MM | 2-6mm | up to 6000MM |
| 125-210 | 133MM-219MM | 2-10mm | |
| 250-550 | 273MM-559MM | 3-15mm | |
| 600-1200 | 610MM-1220MM | 4-28MM | |
| Specification Details | ||
| 1/2"-4" (DN 15-100) | 5"-8"(DN 125-200) | 10"-48"(DN 250-1200) |
| Schedule 5S to Schedule 80 | Schedule 10S to Schedule 80 | Schedule 10S to 28mm |
| Seamless | Weld | Weld |
| Name | Titanium Pipe, zirconium pipe, nickel pipe | |||||||
| Material | Gr1, Gr2, Gr7, Gr12 | |||||||
| Specification | 2.1/2"-48" Schedule 5s to Schedule 80 | |||||||
| Standard | ASTM B862 | |||||||
| Surface Processing | quartz-shot, sand-blasting, polishing | |||||||
| Month capacity | 10 MT | |||||||
| Application | Seawater desalinaton, metallurgy, shipyard, petrochemical, oil refinery | |||||||
| EN 10204-3.1 Certificate (Partial Reference) | ||||||||
| Requirement | Ti | N | C | H | Fe | O | Residual Element | |
| Remainder | ≤ | ≤ | ≤ | ≤ | ≤ | Each | Total | |
| Required | 0.03 | 0.1 | 0.015 | 0.3 | 0.25 | 0.1 | 0.4 | |
| Result | ST-01 | 0.02 | 0.02 | 0.001 | 0.044 | 0.06 | ≤0.1 | ≤0.4 |
| Tensile Test | ||||||||
| Requirement MIN | Lot No. | Tensile Strength | Yield Strength 0.2% | Elongation | ||||
| [MPa] | [MPa] | [%] | ||||||
| 345 MIN. | 275-450. | 20 MIN. | ||||||
| Result | ST-01 | 460 | 372 | 34 | ||||
| Tests |
| DPI, PMI, RT, Hardness test, Bending test, Hydrostatic etc |
