| Place of Origin: | China/Japan/Germany |
|---|---|
| Brand Name: | TOBO/TPCO/TISCO/VALIN/METAL |
| Certification: | ISO/PED/TUV/SGS/LR/BV |
| Model Number: | Copper Foil Tape |
| Minimum Order Quantity: | 0.5-1 tons |
| Price: | negotiable |
| Packaging Details: | in plastic bags then in bundles |
| Delivery Time: | According to the qty |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 1500 tons per month |
| Thk: | 0.3-5mm | Material: | Copper Foil Tape |
|---|---|---|---|
| Color: | White Silver Gold | Standard: | ASTM, |
| Highlight: | Stainless Steel Coils,Stainless Steel Flat Sheets |
||
12mm x 50m - Copper Foil Tape with Conductive Adhesive for EMI Shielding
Detailed Product Description
| Brand Name: | TOBO |
| Model Number: | Copper |
| Certification: | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Place of Origin: | China |
| Product Name: | 12mm x 50m - Copper Foil Tape with Conductive Adhesive for EMI Shielding | Alloy Number: | C11000 |
|---|---|---|---|
| Ordinary Thickness: | 0.018mm,0.025mm,0.035mm,0.050mm | Width (Max): | 500mm |
| Cu Density: | 8.9g/cm3 | Application: | Electric Conductive |
| Length: | 50m/volume | HS Code: | 7410219000 |
12mm x 50m - Copper Foil EMI Shielding Conductive Adhesive Tape
The tape consisting a copper foil backing coated with conductive acrylic pressure sensitive adhesive.
Product Feature:
- Heat preservation, heat insulation
- Waterproof, cold and heat resistance
- Strong adhesion and easily peeled off
- EMI shielding
- UV resistance, flame retardant
- Moisture resistance, chemical and corrosion resistance
- Ideal for outdoor application and durable
Application:
- Single conductive and double conductive
- Eliminate the effect of EMI
- Avoid unnecessary current and voltage
- Ideal for transformer, mobile phone, computer, PDA, PDP, and LCD monitor, PC, copier etc.
- Self adhesive aluminum foil tape used in fridge, air conditioner, automotive, bridge, hotel, electronic industry etc.
Technical Data:
Color: Copper
Carrier: Copper Foil
Adhesive: Conductive Acrylic Adhesive
Carrier Thickness (mm): 0.025
Total Thickness (mm): 0.06 ± 0.005
Appearance: Excellent, no oxidation
Initial Tack(Steel Ball) (#): 11
Resistance(ohm/in2): ＜0.05
Holding Power(1kg/inch): ≥1140
180°Peeling Strength: ＞8 N/25.4mm
Application Temperature: -20~120℃
Storage Condition: 20℃, 65% RH
Table 1:Copper Foil Characteristics:
| Standard(Copper Foil Thickness) | Performance | ||||
| Width(mm) |
Length (m/Volume) |
Adhesion | Peer Force (kg/25mm) |
Adhesive Conduction |
|
| 0.018mm Single-sided | 5-500mm | 50 | Non-Conductive | 1.0-1.4 | No |
| 0.018mm Double-sided | 5-500mm | 50 | Conductive | 1.0-1.4 | Yes |
| 0.025mm Single-sided | 5-500mm | 50 | Non-conductive | 1.0-1.4 | No |
| 0.025mm Double-sided | 5-500mm | 50 | Conductive | 1.0-1.4 | Yes |
| 0.035mm Single-sided | 5-500mm | 50 | Non-conductive | 1.0-1.4 | No |
| 0.035mm Double-sided | 5-500mm | 50 | Conductive | 1.0-1.4 | Yes |
| 0.050mm Single-sided | 5-500mm | 50 | Non-conductive | 1.0-1.4 | No |
| 0.050mm Double-sided | 5-500mm | 50 | Conductive | 1.0-1.4 | Yes |
Notes:1, can be used below 100℃
2, Elongation is at about 5%, but can be changed in accordance with customer specifications.
3, Should be stored in a room temperature and can be stored for less than one year.
4, When in use, keep adhesive side clean of unwanted particles, and avoid repeated use.
