cu-ni 90/10 C70600 seamless copper nickel alloy tube, copper tube copper Nickle Tube

Basic Information

Place of Origin:	China/Japan/Germany
Brand Name:	TOBO/TPCO/TISCO/VALIN/METAL
Certification:	ISO/PED/TUV/SGS/LR/BV
Model Number:	cu-ni 90/10 C70600 s

Minimum Order Quantity:	1PC
Price:	1USD
Packaging Details:	WOODEN CASE
Delivery Time:	15 DAYS
Payment Terms:	T/T, D/A, L/C, D/P, Western Union, MoneyGram
Supply Ability:	9666600000PCS PER MONTH

Get Best Price Contact Now

Standards:

ASTM, AISI, JIS, SUS, EN, DIN, BS, GB

Specifications:

Thickness 1mm To 220mm ,diameter 6mm To 2500mm Or As Customer Required

Copper Tube::

90/10 Copper Nickel Tubes

Surface Treatment:

Solution Annealing/Light Draw/Stress Relieving Heat Treatment

Highlight:

Copper Nickel Alloy Pipe

copper nickel pipe

Cu-ni 90/10 C70600 seamless copper nickel alloy tube, copper tube copper Nickle Tube

Name	seamless copper ( nickel ) pipe and tube
Standard	ASME SB165, SB111, etc.
Material	C44300(brass alloys), C70600(90-10), C68700(CZ110 Aluminium barss alloy), C71500(70-30), C71640(66-30-2-2),etc.
OD	6-219.1mm
WT	0.7-12.7mm
Length	0-38000mm
Surface treatment	solution annealing/Light Draw/Stress Relieving Heat Treatment
Test requirement	1.100% PMI / SPECTRO CHEMICAL ANALYSIS TESTS 100% PMI 2.100% DIMENSION TESTS & 100% VISUAL EXAMINATION 3.TENSION TEST, FLARING TESTS(FOR SEAMLESS TUBE/PIPE)/FLANGE TESTS(FOR WELDED TUBE/PIPE), HARDNESS TEST, REVERSED FLATTENING TEST 4.100% HYDROSTATIC TEST/100% NON-DESTRUCTIVE TESTS NOTES : ALL THE TESTS AND INSPECTION NEED TO PROVIDE WITH REPORTS ACCORDING TO STANDARD AND TEST RESULTS. OPTION TEST & INSPECTION ITEMS: 1.STRAIGHTNESS TEST 2.ROUGHNESS TEST 3.CRYSTALLING PHASE ANALYSIS 4.INTERGRANULAR ATTACK TESTS 5.SHIPPING NOTIFICATION BEFORE SHIPMENT 6 .IMPACT ATTACK TEST UNDER LOW TEMPERATURE. THE DOCUMENT LSI WILL PROVIDE YOU: a. MTC (MATERIAL TEST CERTIFICATION) ACCORDING TO EN10204/3.1 OR EN10204/3.2; b.RAW MATERIAL CERTIFICATION c.ALL THE TEST & INSPECTION REPORTS AS PER PO AND STANDARDS d.HEAT TREATMENT REPORT e.SHIPPING NOTIFICATION BEFORE SHIPMENT f.QUALITY WARRANTY LETTER.
Package	In bundles, plywood cases, wooden cases with water-proof package, etc.
Product processing	Cold drawn, cold rolled
Product origin	Jiangsu, China(main land).
Ends	PE, BE.
Trade terms	FOB, CIF, CFR, DDP, EXW, etc.
Delivery	Container, LCL, consignment.

Name	seamless copper ( nickel ) pipe and tube
Standard	ASME SB165, SB111, etc.
Material	C44300(brass alloys), C70600(90-10), C68700(CZ110 Aluminium barss alloy), C71500(70-30), C71640(66-30-2-2),etc.
OD	6-219.1mm
WT	0.7-12.7mm
Length	0-38000mm
Surface treatment	solution annealing/Light Draw/Stress Relieving Heat Treatment
Test requirement	1.100% PMI / SPECTRO CHEMICAL ANALYSIS TESTS 100% PMI 2.100% DIMENSION TESTS & 100% VISUAL EXAMINATION 3.TENSION TEST, FLARING TESTS(FOR SEAMLESS TUBE/PIPE)/FLANGE TESTS(FOR WELDED TUBE/PIPE), HARDNESS TEST, REVERSED FLATTENING TEST 4.100% HYDROSTATIC TEST/100% NON-DESTRUCTIVE TESTS NOTES : ALL THE TESTS AND INSPECTION NEED TO PROVIDE WITH REPORTS ACCORDING TO STANDARD AND TEST RESULTS. OPTION TEST & INSPECTION ITEMS: 1.STRAIGHTNESS TEST 2.ROUGHNESS TEST 3.CRYSTALLING PHASE ANALYSIS 4.INTERGRANULAR ATTACK TESTS 5.SHIPPING NOTIFICATION BEFORE SHIPMENT 6 .IMPACT ATTACK TEST UNDER LOW TEMPERATURE. THE DOCUMENT LSI WILL PROVIDE YOU: a. MTC (MATERIAL TEST CERTIFICATION) ACCORDING TO EN10204/3.1 OR EN10204/3.2; b.RAW MATERIAL CERTIFICATION c.ALL THE TEST & INSPECTION REPORTS AS PER PO AND STANDARDS d.HEAT TREATMENT REPORT e.SHIPPING NOTIFICATION BEFORE SHIPMENT f.QUALITY WARRANTY LETTER.
Package	In bundles, plywood cases, wooden cases with water-proof package, etc.
Product processing	Cold drawn, cold rolled
Product origin	Jiangsu, China(main land).
Ends	PE, BE.
Trade terms	FOB, CIF, CFR, DDP, EXW, etc.
Delivery	Container, LCL, consignment.

2.Chemical composition:

Copper Nickel Tube
Grade	Cu	Pb	Fe	Zn	Mn	Ni+Co
C70400	Balance	≤0.05	1.3-1.7	≤1.0	0.3-0.8	4.8-6.2
C70600	Balance	≤0.05	1.0-1.8	≤1.0	≤1.0	9.0-11.0
C70620	≥86.5	≤0.02	1.0-1.8	≤0.50	≤1.0	9.0-11.0
C71000	Balance	≤0.05	0.5-1.0	≤1.0	≤1.0	19.0-23.0
C71500	Balance	≤0.05	0.4-1.0	≤1.0	≤1.0	29.0-33.0
C71520	≥65.0	≤0.02	0.4-1.0	≤0.50	≤1.0	29.0-33.0
