TOBO GROUP
TOBO International Trading(Shanghia)Co.,Ltd Tianda Oil Pipe Co., Ltd
TOBO Pipeline Equipment Co.,Ltd TPCO & TISCO Pipe(Tianjin)Co.,Ltd.
| Place of Origin: | China |
|---|---|
| Brand Name: | TOBO |
| Certification: | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Model Number: | Square Flange |
| Minimum Order Quantity: | 300 Kilogram/Kilograms |
| Price: | US $ 10 - 100 / Kilogram |
| Packaging Details: | Seaworthy wooden cases or pallets tied by steel band or as per client's requirements |
| Delivery Time: | 30 days After Receiving the 30% Prepayment by T/T or LC |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 50 Metric Ton/Metric Tons per Month |
| Product Name: | Weld Neck Flange | Product Type: | Slip-on, Thread, Socket Weld |
|---|---|---|---|
| Standard: | ANSI, ANSI B16.5,B16.47 | Size: | 1/2''-60", 1/2" To 60" |
| Material: | Stainless Steel | Application: | Blades, Vanes, Shafts, Tail Cones, Afterburners, Springs, And Fastener |
| Color: | Shining | ||
| Highlight: | forged fittings and flanges,butt weld flanges |
||
150 LBS Slip On PN16 High Pressure Square Flange ANSI Reducer Flange
| Size: |
1/2''-60", 1/2" to 60"
|
Material: |
Stainless Steel
|
Standard: |
ANSI, ANSI B16.5,B16.47
|
| Place of Origin: |
Shanghai/CHINA
|
Model Number: |
FLANGE
|
Brand Name: |
TOBO
|
| Standard or Nonstandard: |
Standard
|
MATERIAL: |
STAINLESS STEEL,CARBON STEEL
|
Pressure: |
Class 150, 300,600,900,1500
|
| Type: |
Slip-on, Thread, Socket Weld
|
Style: |
Welding Neck, Blind,PLATE
|
Package: |
Standard export package
|
| Shipping Method: |
Ocean or Air
|
MOQ: |
negotiation
|
| Packaging Details: | CARTON, PLYWOOD PALLET, PLYWOOD CASE |
| Delivery Detail: | AS REQUESTED |
Production Specification
|
Product Name |
150 lbs slip on pn16 high pressure square flange ansi reducer flange |
|
Model Number |
Flange |
|
Pressure |
Class 150 / Class 300LB |
|
Size Range |
1/2" to 60" |
|
Standard Available |
1. ASME B16.5 (1/2"~24") 2. ASME B16.47 (26"~60") 2. MSS Flange: Steel Pipe Flanges 3. JIS B2220: JIS 10K, JIS 20K, JIS 40K 4. DIN Flange: DIN 2501, DIN2576,DIN2633,DIN2278,DIN2634,DIN2635,DIN 2637,DIN 2527, DIN 2642 PN10,PN16,PN40 5. BS EN1092-1: Flanges and their joints — Circular flanges for pipes,valves, fittings and accessories, PN designated 6. BS 4504 FLANGE :CIRCULAR FLANGES FOR PIPES , VALVES AND FITTINGS PN6,PN10,PN16 7. AS 2129 FLANGES: Flanges for pipes, valves and fittings |
|
Material |
WCB, CF8, CF8M |
|
Flange Types |
1. Welding Neck flange 2. Socket Weld flange 3. Lap Joint flange 4. Stub End 5. Threaded flange 6. Blind flange 7. OEM / ODM Product |
|
Quality Inspection |
Mill Certificate 3.1 and/or other per your request |
|
Certification |
ISO, CE, CRN, AD2000, API 607 5th Edition, NACE MR-0175 |
|
Lead Time |
Based on the quantity, sample order available |
|
Terms |
EX-WORK, FOB, CIF, C&F |
|
Payment |
T/T, LC Before shipment for first order. |
|
Place of Origin |
China / Taiwan |
Packing Information
|
Product Name |
150 lbs slip on pn16 high pressure square flange ansi reducer flange |
|
Model |
Flange |
|
Label |
As per customer’s request |
|
Packing method |
CARTON, PLYWOOD PALLET, PLYWOOD CASE |
|
Delivery |
Transport by Sea / Air / Express / Pickup |
