Aisi 316 Grade S32750 Super Duplex Stainless Steel Tube Rode Customized Cylinder Piston Rod

Basic Information

Place of Origin:	China/Japan/Germany
Brand Name:	TOBO/TPCO/TISCO/VALIN/METAL
Certification:	ISO/PED/TUV/SGS/LR/BV
Model Number:	1.4835 Stainless Steel Seamless Pipe

Minimum Order Quantity:	0.5-1 tons
Price:	negotiable
Packaging Details:	in plastic bags then in bundles
Delivery Time:	15days->
Payment Terms:	T/T, L/C, Western Union, MoneyGram
Supply Ability:	7500 tons per year

Get Best Price Contact Now

Standard::	DIN, ANSI, ISO, GB, JIS	Application:	Fluid Pipe,Structure Pipe
Surface:	Annealed & Pickled, Bright Annealing, Polished	Types::	Seamless
Thickness:	0.5-100mm	Outer Diameter:	6-813mm
Material:	Carbon Steel,Stainless Steel,alloy Steel,Brass,copper	Sample:	Provided,Free,Available Free Within 7days
Highlight:	Aisi 316 Cylinder Piston Rod , Duplex Stainless Steel Cylinder Piston Rod

Aisi 316 Grade,S32750,Super Duplex Stainless Steel Tube,Rode,Customized Cylinder Piston Rod

Overview

Quick Details

Place of Origin:: China

Application:: Hydraulic Pipe, Gas Pipe, OIL PIPE

Alloy Or Not:: Is Alloy

Section Shape:: Round

Special Pipe:: API Pipe, Thick Wall Pipe, Other

Outer Diameter:: 40 - 1200 mm

Thickness:: AS REQUESTED

Standard:: ASTM

Length:: 6m

Certificate:: API, ISO9001

Grade:: 20MnCr5H/40CrNiMoA/16MnCr5/34CrNiMo6/SAE 4340

Surface Treatment:: Cold Rolled

Tolerance:: ±5%

Processing Service:: Welding, Cutting, Bending

Oiled or Non-oiled:: Slightly Oiled

Invoicing:: by actual weight

Delivery Time:: 15-21 days

Chrome thickness:: 0-30μm(min) or According to customer's requirement

Product Name:: Seamless Steel Pipe

Technique:: Cold Rolled Hot Rolled, Cold Drawn

Packaging & Delivery

Selling Units:: Single item

Single package size:: 60X60X610 cm

Single gross weight:: 5.221 kg

Package Type:

Bundling, wood packing, according to customer demand

Picture Example:

Lead Time:

Quantity(tons)	1 - 1	>1
Est. Time(days)	15	To be negotiated

Product Description

Specification

Processing method	ID	Length	Straightness	Tolerance for ID	Tolerance for thickness	ID Roughness
Cold drawn	40-320	≤12m	0.2-0.5	H8-H10	±5%	0.8-1.6
Cold drawn-Honing	40-500	8m	0.2-0.3	H8-H9	±5%	0.2-0.8
Cold drawn-Rolling	40-400	7m	0.2-0.3	H8-H9	±5%	0.2-0.4
Deep Hole Boring-Honing	320-1200	8m	0.2-0.3	H8-H9	±8%	0.2-0.8
Deep Hole Boring-Rolling	320-1200	7m	0.2-0.3	H8-H9	±8%	0.2-0.4

Mechnical properties

Steel grade	Tensile strength (Mpa)	Yield strength (Mpa)	Elongation(%)	Hardness
20#	550	440	12	175
45#	645	516	6	207
16Mn	640	512	9	190

Toblerance for hond t or skived and burnished tubes

ID(mm)	Tolerance for ID(μm)
ID(mm)	H7	H8	H9	H10
>40-50	0~+25	0~+39	0~+62	0~+100
>50-80	0~+30	0~+46	0~+74	0~+120
>80-120	0~+35	0~+54	0~+87	0~+140
>120-180	0~+40	0~+63	0~+100	0~+160
>250-315	0~+52	0~+81	0~+130	0~+210
>315-400	0~+57	0~+89	0~+140	0~+230
>400-500	0~+63	0~+97	0~+155	0~+250
>500-630	0~+70	0~+110	0~+175	0~+280
>630-800	0~+80	0~+125	0~+200	0~+320
>800-1000	0~+90	0~+140	0~+230	0~+360
>1000-1200	0~+105	0~+165	0~+260	0~+420

Packing & Delivery

Bundling, wood packing, according to customer demand

FAQ

Q: Does this tubing come with triclamp ends to be coupled together?A: This particular tubing comes without tri-clamp ends standard. We can always weld tri-clamp ferrules to the end of tubes for any specific length you need. These products are referred to as tri-clamp spool assemblies. If you need a specific length, please

contact us.

Q: Are you able to cut tubing to lengths that don't require freight shipping? Say 5' lengths for example.?
A:Yes, we are able to cut down to other sizes. UPS Ground is able to ship up to 7' without the tubing being considered "oversized".We do charge a cutting fee for this service, however. Please contact us for a quote.

Q:How much does 1 stick of 4" tube weigh?
A: One 20' Stick of 4" Sanitary Tubing weighs approximately 75 pounds.

Q:You list gauge of this tubing at 16, but the wall thickness at 0.065". Isn't 16 gauge 0.0625"?
A: The wall thickness and gauges are all displayed in the table below. Please contact us if you have any other questions.

Q: Do you sell tubing in anything less than cases? I need to order just over 400 feet but don't want to pay for two cases as this is More than I need.

A:  We do sell tubing on an individual basis however there is a $50 "broken box" fee applied to any order less than an entire case.Since we don't offer a way to order individual tube pieces online please call us to place an order over the phone.

Q: Do this product ship via freight?

A: Yes, our tubing comes in standard 20 foot lengths and will need to ship via freight. I'd also like to mention that there is a broken box charge meaning that if you do not order an entire box of tubing you will be charge additional fees as such. For more information please contact us. Thanks.
