| Place of Origin: | China |
|---|---|
| Brand Name: | TOBO |
| Certification: | ISO9001:2008 |
| Model Number: | TOBO-52 |
| Minimum Order Quantity: | 1 TON |
| Price: | negotiable |
| Packaging Details: | Thick Wooden Box Packing |
| Delivery Time: | 7-15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 500 TON PER MONTH |
| Product Name: | TOBO Nickel Alloy Pipe | Grade: | 10#-45#, 16Mn, A53-A369 |
|---|---|---|---|
| Wall Thickness: | 1 - 8 Mm | Place Of Origin: | China |
| OD: | 6 - 65 Mm | Length: | As Your Requested |
| Brand: | TOBO | Standard: | API, ASTM, DIN, GB, API 5L |
| Highlight: | Thin Wall Steel Pipe,Alloy Steel Seamless Pipe |
||
Product description & packaging & shipping
12Cr1MoVG Fast Delivery High Quality Alloy Steel Pipe Seamless Alloy Steel Pipe
|
Item
|
Factory price ASTM A335 P91 P11 P22 P5 seamless alloy steel pipe |
| Standard |
ASTM A213,ASTM A335,ASTM A200,GB9948,GB5310,GB6479,
JIS3462,JIS3458,JIS3467,DIN 17175 |
| Material |
ASTM A213 T2/T12/T11/T22/T5/T9,ASTM A200 T11/T22/T5/T9,
ASTM A335 P2/P12/P11/P22/P5/P9,12CrMo,15CrMo,12Cr2Mo,1Cr5Mo,etc.
|
| Dimension | Wall thickness: 1mm-120mm |
| Outside Diameter: 6mm-2400mm | |
| Length: 5.8m,6m,11.8m,12m or as you require | |
| Surface |
Black painted,PE coating,galvanized,etc |
| Export to |
Alloy steel pipe is exported to : America,Germany,Thailand,Singapore,Australia,France,Iran,Indian,Iraq, Turkey,Brazil,Korea,Italy,and so on. |
| Payment terms |
EXW,FOB,CNF,CIF,CFR,etc.
|
| Application | Petroleum,chemical industry,electric power,boiler,
low temperature resistant,high temperature resistant, alloy steel pipe also can be made according customer's required. |
| Grade | Standard | C | Si | Mn | V | Mo | Cr | P | S | Yield strength MAp | Tensile strength MAp | Elongation % |
| 12Cr1MoVG | GB5130 | 0.08-0.15 | 0.17-0.37 | 0.40-0.70 | 0.15-0.30 | 0.25-0.35 | 0.90-1.2 | ≤0.03 | ≤0.03 | 255 | 470-640 | 21 |
| Outer Diameters: | 32mm -720mm |
| Wall thickness: | 6mm-80mm |
| Length : | 5000mm-13000mm |
| packaging |
1. by bundles, each bundle weight under 3 tons, for small outer diameter seamless steel pipe, each bundle with 4 - 8 steel strips. 2. after making by bundle, covered with Polyethylene waterproof cloth. 3. make black paints painting on each pipe, then make bundles |
| Delivery time; | 7 days for stock sizes, 10-15 days for new production sizes |
| Port: | Shanghai China |
Our Services
12Cr1MoVG Fast Delivery High Quality Alloy Steel Pipe Seamless Alloy Steel Pipe
* 1 .can cut the seamless steel pipe into the length you demand
* 2 .can make the surface to be bright by milling and grinding at the Lathe
* 3 .can grind the outer diameter and wall thickness to be the dimension you demand
* 4 .can make steel pipes deep processing.
If the sizes are not available from the standard common stock sizes, and the quantity are not enough for the new production, then we need process the stock larger seamless pipes into the sizes you need.For example, size OD250x ID200 is not stock common size, then need using larger pipe to process into 250x 200, same as OD170xID100.
Product Description
Steel Pipes and Tubes
Standard: GB/T3091, ASTM A53, BS1387
Material: A106B, A53, 20, 20G
O. D.: 6mm-460mm
W. T: 1.2mm-16mm
Length: 6-12m, can be customized
Application:
Seamless steel pipes for low and medium pressure boiler, high pressure boiler, ship-building, liquid service, petroleum cracking, chemical fertilizer equipment, Drawing-oil-equipment and structure purposes.
Packing: Bundles, seaworthy packing
Nominal Diameter |
Outer Diameter |
Wall Thickness mm |
|||||||||||||||
| 1.2 | 1.5 | 1.75 | 2 | 2.5 | 3 | 3.5 | 4 | 5 | 6 | 8 | 10 | 12 | 12.5 | 16 | |||
| Inch | mm | mm | Calculated Weight ( Kg/m ) | ||||||||||||||
| 1/2 | DN15 | 21.3 | 0.59 | 0.73 | 0.84 | 0.95 | 1.16 | 1.35 | |||||||||
| 3/4 | DN20 | 26.8 | 0.76 | 0.94 | 1.08 | 1.22 | 1.5 | 1.76 | |||||||||
| 1 | DN25 | 33.5 | 1.18 | 1.55 | 1.91 | 2.26 | 2.59 | 2.91 | |||||||||
| 1.25 | DN32 | 42.3 | 1.51 | 1.99 | 2.45 | 2.91 | 3.78 | ||||||||||
| 1.5 | DN40 | 48 | 1.72 | 2.27 | 2.81 | 3.33 | 4.34 | 5.3 | |||||||||
| 2 | DN50 | 60 | 2.86 | 3.55 | 4.22 | 5.52 | 6.78 | ||||||||||
| 2.5 | DN65 | 75.5 | --- | 4.5 | 5.36 | 7.05 | 8.69 | ||||||||||
| 3 | DN80 | 88.5 | 6.33 | 8.34 | 10.3 | 12.21 | |||||||||||
| 4 | DN100 | 114 | 10.85 | 13.44 | 15.98 | ||||||||||||
| 5 | DN125 | 140 | 13.42 | 16.65 | 19.83 | ||||||||||||
| 6 | DN150 | 165 | 15.88 | 19.73 | 23.53 | 30.97 | |||||||||||
| 8 | DN200 | 219.1 | 26.4 | 31.53 | 41.6 | 51.6 | |||||||||||
| 10 | DN250 | 273 | 33.0 | 39.5 | 52.3 | 64.9 | |||||||||||
| 12 | DN300 | 325 | 39.5 | 47.2 | 62.5 | 77.7 | 92.6 | ||||||||||
| 14 | DN350 | 355.6 | 51.7 | 68.6 | 85.2 | 101.7 | |||||||||||
| 16 | DN400 | 406.4 | 78.6 | 97.8 | 116.7 | ||||||||||||
| 18 | DN450 | 457 | 88.6 | 110.0 | 131.7 | ||||||||||||
| 20 | DN500 | 508 | 98.6 | 123.0 | 146.8 | ||||||||||||
| 24 | DN600 | 610 | 118.8 | 148.0 | 184.2 | 234.4 | |||||||||||
Factory price ASTM A335 P91 P11 P22 P5 seamless alloy steel pipe can be packed in bulk, in bundle with steel trip, tarpaulin and plastic outside or according to customers' requirements, look at the pictures as follow:
A: We are factory.
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
Email:Summer@tobo-group.com
