| Place of Origin: | China |
|---|---|
| Brand Name: | TOBO |
| Certification: | ISO 9001:2008 |
| Model Number: | TOBO57 |
| Minimum Order Quantity: | 1 pcs |
| Price: | 1 USD |
| Packaging Details: | In plywood cases and pallets |
| Delivery Time: | 7-15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1100000 Pcs per month |
| Product Name: | TOBO Flange | Material: | ASTM/ASME S/A182 F44, F904L, F317L |
|---|---|---|---|
| Size: | (150#,300#,600#): DN15-DN1500 | Type: | WN SO PL TH SW LJ BL LWN LOOSE Orifice |
| Class: | 150# 300# 900#1500#,2500#,3000#,6000#,9000# | Standard: | API, ISO, SGS, BV, CE, |
| Brand: | TOBO | ||
| Highlight: | forgings flanges and fittings,forged fittings and flanges |
||
| Product Name | Carbon steel / Stainless steel / Alloy Flanges |
| Standard | ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Type |
SW Flange Special Flange: According to the drawing Picture |
| Materials |
Nickel Alloy: ASTM/ASME S/B366 UNS N08020, N04400, N06600, N06625, N08800, N08810, N08825, N10276,N10665,N10675 Carbon Steel: ASTM/ASME S/A105, ASTM/ASME S/A350 LF2, ASTM/ASME S/A694/A694M, F42, F52, F56, F60, F65, F70....ASTM/ASME S/A350 LF2, ASTM/ASME S/A694/A694M, F42, F52, F56, F60, F65, F70.... |
| Dimension | (150#,300#,600#): DN15-DN1500 900# : DN15-DN1000 1500#: DN15-DN600 2500#:D N15-DN300 |
| Marking | Supply Logo + Standard + Size(mm) + HEAT NO +or as your requirement |
| Test | Chemical Component Analysis, Mechanical Properties, Metallurgical Analysis, Impact Testing, Hardness testing , Ferrite Testing, Intergranular corrosion testing, X-ray Inspection (RT), PMI, PT, UT, HIC & SSC test, etc. or as your requirement |
| Brand | TOBO Group |
| Certificates | API, ISO, SGS, BV, CE, PED, KOC, CCRC, PDO, CH2M HILL and etc. |
| Advantages |
1. Abundant stock and prompt delivery 2. Reasonable for whole packages and processes. 4. More than 150 customers spread worldwide. |
| Packing | In wooden case, pallets or as per customers’requirement | ||
| Delivery | 7-25days after the PO | ||
| Stainless Steel: |
| ASTM A 182, ASTM A 240, ASTM A 182 F304, F304L, 304H, 316, 316L, 316H, 316Ti, 321, 309, 310, 347, 904L, etc. |
| Duplex Stainless Steel : |
| Other Grades: 2507, 2205, 2304, 153MA, 253MA, 309, 904L, 2595MO. |
| Nickel Other Grade: |
| ASTM / ASME SB 564 UNS 2200 ( NICKEL 200 ) , UNS 4400 (MONEL 400 ) , , UNS 8825 INCONEL (825) , UNS 6600 (INCONEL 600 ) , UNS 6601 ( INCONEL 601 ) , UNS 6625 (INCONEL 625) , UNS 10276 ( HASTELLOY C 276 ) ASTM / ASME SB 160 UNS 2201 (NICKEL 201 ) ASTM / ASME SB 472 UNS 8020 ( ALLOY 20 / 20 CB 3 ) ASTM / ASME SA 182 F 304 , 304L , 304H, 309H, 310H , 316 , 316H , 316L , 316 LN , 317 , 317L , 321 , 321H , 347 347 H |
| Carbon Steel: |
| ASTM A 105, ASTM A 181 |
| Alloy Steel: |
| ASTM A 182, GR F1, F11, F22, F5, F9, F91 |
| Nickel Alloys: |
| Monel 400 & 500, Inconel 600 & 625, Incolloy 800, 825, Hastelloy 904 |
| Copper Alloys: |
| Aluminium, Copper, Brass & Gunmetal |
| Types: |
| Weldneck, Slipon, Blind, Socket Weld, Lap Joint,Loose, Screwed, Spectacles Blind, Ringjoint, Oriface, Long Weldneck, Deck Flange, Threaded etc. |
| Flange Facing: |
| Raised Face, Flat Face, Small & Large Male-Female, Small & Larged Tongue & Groove, Ring Joint |
| Dimension: |
| ANSI B 16.5, DIN Standaed, JIS Standard, BS 10 etc. |
| Standard: |
| 125#,150#, 300#, 600#, 900#, 1500#,2500#,3000#, 5000# & 10000#, Table D, E, F, H, ND6, ND25, ND16, ND40, ND64, ND100, etc |
" ANSI STD 150LBS, 300 LBS"
DIN STD PN16~PN 250. 1/2”~24”
JIS STD 5K~20K. 1/2”~24”
UNS S32750 SUPER DUPLEX STEEL LAP JOINT FLANGE
Products Description:
Lap joint flanges are always used with either a stub end or taft which is butt welded to the pipe with the flange loose behind it. This means the stub end or taft always makes the face. The lap joint is favoured in low pressure applications because it is easily assembled and aligned. To reduce cost these flanges can be supplied without a hub and/or in treated, coated carbon steel.
Standards: ANSI, MSS, API, AWWA, DIN, JIS, BS and GB.
Process: free forging, plate cutting.
Sizes range: 1/2" to 64" (and much larger size according to customers' demands).
Materials: Carbon steel, stainless steel and alloy steel.
Printing: Carbon steel and alloy steel with yellow print, black print, oil or zinc.
Packing: in wooden cases, wooden pallets or as per customers' special requirement, Standard Export Package.
* We can also manufacture special application flanges and forgings that customers require.
Skype: 17717932304
Or send to summer[at]tobo-group.com
Size:
ANSI 1/2, 3/4, 1, 1 1/4, 1 1/2, 2, 2 1/2, 3, 3 1/2, 4, 5, 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 28, 30, 32, 34, 36, 38, 40, 42, 44, 46, 48, 50, 52, 54, 60, 66, 72, 78, 84, 90, 96, 102, 108, 114, 120 inch(") and etc.
DN 10, 15, 20, 25, 32, 40, 50, 65, 80, 100, 125, 150, 200, 250, 300, 350, 400, 500, 600, 700, 800, 900, 1000, 1200, 1400, 1600, 1800, 2000, 2200, 2400, 2600, 2800, 3000, 3200, 3400, 3600, 3800, 4000 MM and etc.
| Type |
Slip on flange,welding neck flange,butt welding flange,socket welding flange, lap joint flange,thread flange,plate flange,blind flange |
| Material | 20#,A105,Q235A ,12Cr1MoV ,16MnR,15CrMo,18-8,321,304,304L,316,316L |
| Technics | Forged |
| Standard | ASME B16.5, DIN2505,JIS/KS(5K,10K,16K,20K),GB,JG,HG |
| Nominal Diameter | 1/2’’—72’’inch DN15mm-DN1800mm |
| Nominal Wall Thickness | SCH5s--SCH160 STD XS XXS |
| Surface Treatment | Rust-proof oil, black painted or as per customers’ requirement |
| Sealing Surface Form | RF, FF, FM, M, TG, RJ,RTJ |
| Certificate | ISO9001-2008 |
| Packing | Plywood case/pallet, steel pallet or as per customers’ requirement |
| Payment | T/T, L/C |
| Factory | Over 15 years experience |
| Application |
Chemical,petroleum,electric power, water conservancy, pharmaceutical, boiler, ship, etc |
| Delivery | Normally 15-25 days or as per customer’s requirement |
